505M-blow
Blow Distance 10m
Tractor
Power (min.) 80HP / 60kW
505M-length
Overall Length 2.36m
Weight
Weight 877kg
bale size
Straw Bale 1 x 5'

Why choose the 505M?

Straightforward operation, precision processing.

Process round or rectangular bales of dry material to a consistent length from 8mm to 120mm, depending on mill screen size. Output up to 3 t/hr. with uniform chop length for optimal nutrition and bedding.

Key Benefits:

  • Precision Output: Delivers a fine uniform chop from the high performance mill system. Output can be calibrated by changing screens in the mill.

  • Efficient operation: The unique rotor design, developed over many years, requires low HP and delivers high output.

Explore the 505M

Highlights
Features
Options
Overview
Tomahawk 505M highlights
Calibrated Output
Calibrated Output
Calibrated Output

Hardox Screens are interchangable, with hole diameters from 8mm - 120mm.

Discharge to one or both sides
Discharge to one or both sides
Discharge to one or both sides

Chutes on left and right hand sides can be open or shut independently. Various chutes are available for special applications. See Options.

Precision Processing
Precision Processing
Precision Processing

Bales of dry material (<20% moisture) are milled to a precise length by 40 blades (20 hammer option also available), with chop length controlled by a hardox screen.

Cat. II/III Linkage
Cat. II/III Linkage
Cat. II/III Linkage

All models in the Tomahawk 500 series are now compatible with both Cat. II and Cat. III tractor linkages.

Driveline protection
Driveline protection
Driveline protection

PTO is supplied as standard with friction clutch overload protection. Tractor PTO speed is 1000rpm. Optional 21 spline version available.

Lower Left Hand Chute
Lower Left Hand Chute
Lower Left Hand Chute

Lower chute (optional for for Multi rotor models 4040 and 5050) enables discharge to both sides.

OPTION : 3m Long Drum
OPTION : 3m Long Drum
OPTION : 3m Long Drum

Long drum (See XL specification) enables a complete large rectangular bale up to 3' x 4' x 8' to be loaded, and for improved material containment..

OPTION : Driveline protection
OPTION : Driveline protection
OPTION : Driveline protection

A wide angle PTO is available for high use operators, with friction clutch overload protection. Optional 8 or 21 spline versions available.

OPTION : Dust seal brush
OPTION : Dust seal brush
OPTION : Dust seal brush

A brush seal kit ensure straw stays in the machine.

OPTION : Dust Suppression Kit
OPTION : Dust Suppression Kit
OPTION : Dust Suppression Kit

The liquid spray kit can be fitted to any model in the 400 - 500 Tomahawk range to reduce dust from milled straw, or to enable the application of anti-bacterial products to bedding.

OPTION : Electric Drive
OPTION : Electric Drive
OPTION : Electric Drive

Simple to use and efficient to run. The Tomahawk 500E offers semi-automated straw processing, with less than half the running cost of a tractor.

OPTION : Feed control
OPTION : Feed control
OPTION : Feed control

For fine control of the drum rotation speed and output, a hydraulic flow divider is available for the T505M.

OPTION : Hose Adaptor
OPTION : Hose Adaptor
OPTION : Hose Adaptor

For connection to 180mm (6") hose. Available for models with lower chute output.

OPTION : Hydraulic Flap Control
OPTION : Hydraulic Flap Control
OPTION : Hydraulic Flap Control

For controlled delivery, available on all Giraffe Chutes.

OPTION : Hydraulic Top Link
OPTION : Hydraulic Top Link
OPTION : Hydraulic Top Link

For straightforward, in-cab adjustment of drum angle and feed rate.

OPTION : Multi Rotor
OPTION : Multi Rotor
OPTION : Multi Rotor

Suitable for processing straw for bedding loose housing (does not chop short), feeding silage & root crops. See model T5050

OPTION : Radio Remote Control
OPTION : Radio Remote Control
OPTION : Radio Remote Control

The radio remote control allows you to remotely trigger mulching while using the hose. Includes: drum speed regulator, power cable, distributor unit, and radio remote control.

OPTION : Straw Giraffe Chute
OPTION : Straw Giraffe Chute
OPTION : Straw Giraffe Chute

Increase delivery height and blow distance. For Mill Rotor models.

OPTION : Strawberry Chute Kit
OPTION : Strawberry Chute Kit
OPTION : Strawberry Chute Kit

To deliver straw directly between row crops, on both sides of the machine.

OPTION : Swivel Giraffe Chute
OPTION : Swivel Giraffe Chute
OPTION : Swivel Giraffe Chute

Increase delivery height, available with hydraulic rotation and deflector. Dry materials only.

OPTION : Tailgate Mesh
OPTION : Tailgate Mesh
OPTION : Tailgate Mesh

Available for all models with tailgates to improve containment.

OPTION : Trailed Chassis
OPTION : Trailed Chassis
OPTION : Trailed Chassis

A trailed chassis to accommodate all models in the Drum Tomahawk range. Convenience, control for smaller tractors.

OPTION :135° chute
OPTION :135° chute
OPTION :135° chute

To deflect straw under the machine when spreading straw evenly when bedding poultry sheds.

British Built
British Built
British Built

Built in Britain. Making an impression worldwide!

A superior finish
A superior finish
A superior finish

All Teagle products are now treated with a double powder coat paint finish; our latest upgrade in product quality and durability.

Save Straw / Save Time
Save Straw / Save Time
Save Straw / Save Time

Users regularly report up to 30% savings by spreading the correct amount of straw evenly across the bedding area.

Highlights
Features
Options
Overview
Tomahawk 505M features
Cat. II/III Linkage
Cat. II/III Linkage
Cat. II/III Linkage

All models in the Tomahawk 500 series are now compatible with both Cat. II and Cat. III tractor linkages.

Driveline protection
Driveline protection
Driveline protection

PTO is supplied as standard with friction clutch overload protection. Tractor PTO speed is 1000rpm. Optional 21 spline version available.

Lower Left Hand Chute
Lower Left Hand Chute
Lower Left Hand Chute

Lower chute (optional for for Multi rotor models 4040 and 5050) enables discharge to both sides.

Highlights
Features
Options
Overview
Tomahawk 505M options
OPTION : 3m Long Drum
OPTION : 3m Long Drum
OPTION : 3m Long Drum

Long drum (See XL specification) enables a complete large rectangular bale up to 3' x 4' x 8' to be loaded, and for improved material containment..

OPTION : Driveline protection
OPTION : Driveline protection
OPTION : Driveline protection

A wide angle PTO is available for high use operators, with friction clutch overload protection. Optional 8 or 21 spline versions available.

OPTION : Dust seal brush
OPTION : Dust seal brush
OPTION : Dust seal brush

A brush seal kit ensure straw stays in the machine.

OPTION : Dust Suppression Kit
OPTION : Dust Suppression Kit
OPTION : Dust Suppression Kit

The liquid spray kit can be fitted to any model in the 400 - 500 Tomahawk range to reduce dust from milled straw, or to enable the application of anti-bacterial products to bedding.

OPTION : Electric Drive
OPTION : Electric Drive
OPTION : Electric Drive

Simple to use and efficient to run. The Tomahawk 500E offers semi-automated straw processing, with less than half the running cost of a tractor.

OPTION : Feed control
OPTION : Feed control
OPTION : Feed control

For fine control of the drum rotation speed and output, a hydraulic flow divider is available for the T505M.

OPTION : Hose Adaptor
OPTION : Hose Adaptor
OPTION : Hose Adaptor

For connection to 180mm (6") hose. Available for models with lower chute output.

OPTION : Hydraulic Flap Control
OPTION : Hydraulic Flap Control
OPTION : Hydraulic Flap Control

For controlled delivery, available on all Giraffe Chutes.

OPTION : Hydraulic Top Link
OPTION : Hydraulic Top Link
OPTION : Hydraulic Top Link

For straightforward, in-cab adjustment of drum angle and feed rate.

OPTION : Multi Rotor
OPTION : Multi Rotor
OPTION : Multi Rotor

Suitable for processing straw for bedding loose housing (does not chop short), feeding silage & root crops. See model T5050

OPTION : Radio Remote Control
OPTION : Radio Remote Control
OPTION : Radio Remote Control

The radio remote control allows you to remotely trigger mulching while using the hose. Includes: drum speed regulator, power cable, distributor unit, and radio remote control.

OPTION : Straw Giraffe Chute
OPTION : Straw Giraffe Chute
OPTION : Straw Giraffe Chute

Increase delivery height and blow distance. For Mill Rotor models.

OPTION : Strawberry Chute Kit
OPTION : Strawberry Chute Kit
OPTION : Strawberry Chute Kit

To deliver straw directly between row crops, on both sides of the machine.

OPTION : Swivel Giraffe Chute
OPTION : Swivel Giraffe Chute
OPTION : Swivel Giraffe Chute

Increase delivery height, available with hydraulic rotation and deflector. Dry materials only.

OPTION : Tailgate Mesh
OPTION : Tailgate Mesh
OPTION : Tailgate Mesh

Available for all models with tailgates to improve containment.

OPTION : Trailed Chassis
OPTION : Trailed Chassis
OPTION : Trailed Chassis

A trailed chassis to accommodate all models in the Drum Tomahawk range. Convenience, control for smaller tractors.

OPTION :135° chute
OPTION :135° chute
OPTION :135° chute

To deflect straw under the machine when spreading straw evenly when bedding poultry sheds.

Highlights
Features
Options
Overview
Tomahawk 505M overview
British Built
British Built
British Built

Built in Britain. Making an impression worldwide!

A superior finish
A superior finish
A superior finish

All Teagle products are now treated with a double powder coat paint finish; our latest upgrade in product quality and durability.

Save Straw / Save Time
Save Straw / Save Time
Save Straw / Save Time

Users regularly report up to 30% savings by spreading the correct amount of straw evenly across the bedding area.

Watch the Tomahawk 505M in action

Tomahawk Drum Range

Specifications

Description
505M505XLM
Rotor
Mill
Mill
Max. round bale diam.
1.50m
1.50m x 2
Max. rect. bale size
N/A
1.20m
Overall height*
2.44m
2.80m
Overall length
2.36m
3.77m
Drum diam.
1.83m
1.83m
Drum length (std)
1.55m
3.00m
Long drum (opt)
1.85m
N/A
Lower chute discharge height*
0.40m
0.40m
Upper chute discharge height*
1.14m
1.14m
Tractor power (min.)**
80HP / 60kW
120HP / 90kW
PTO speed1,000 rpm
1,000 rpm
Transport width***
2.01m
2.01m
Operating width
3.13m
3.13m
Straw giraffe discharge height*
1.84m
1.84m
Weight970kg1,166kg

*Working heights will increase by up to 1m depending on tractor
** Typical tractor size to provide adequate lifting capacity and stability
***Chute extensions not fitted
****No optional left-hand chute fitted
